48-51" Universal Harness Bar

If you’re serious about racing, chances are you either have a 5 or 6 point harness installed in your track vehicle, or you’re thinking about installing one. To accomplish this, however, you’ll need a solid foundation upon which to mount your harness. Your stock seat belt mounting points won’t work; they’re in the wrong location and won’t provide the kind of support you need to stay firmly planted in your seat during hard cornering and collisions. That’s where our universal harness bars come into play. Our harness bars allow you to install 5 or 6 point harnesses in almost any vehicle. They are adjustable so you don’t have to worry about less-than-optimal fitment, or whether or not they can be reused in your next track vehicle. Buy with total confidence.

Our universal harness bars are made of high strength Q195 Carbon Steel with 2mm wall thickness and 1.5" diameter tubing, powder coated in the all-time-favorite colors of glossy white, glossy red, matte black, space grey, bronze and glossy black. They are 48-51" in length to accommodate a broad variety of applications, and allow for 4 point mounting for a stable and secure fit. The lower bars are fitted with high strength, steel, ball joint rod ends for fine-tuned adjustability and fitment catered to your specific vehicle. In addition you will receive high quality hardware for a quick, complete, and reliable installation.

PRODUCT FITMENT

BRAUM does not guarantee the size fitment for any seats, harnesses and/or universal products due to varied vehicle interior dimensions and configurations. Please use the product dimensions provided to compare with your existing layout to determine fitment. BRAUM will not be held liable for incorrect assessments regarding fitment.

Current confirmed vehicle applications :

(**Requires removal or modification to plastic b-pillar panels)

1979-1993 Ford Mustang
1983-1987 Toyota Corolla
1983-1991 VW GTi
1985-1989 Toyota Celica (coupe)
1986-1992 Toyota Supra
1984-1992 VW Jetta [requires reversing both ends on the harness bar to sit properly/flush]
1989-1994 Nissan 240SX (coupe/hatchback) **
1989-1994 Nissan S13 (coupe/hatchback) **
1989-1994 Nissan Maxima
1990-1996 Nissan 300ZX 2+2 [requires mounting the bar from the rear seatbelt points]
1991-1999 Nissan Sentra
1992-1995 Honda Civic [excludes sedan]
1992-1998 BMW 3-series E36
1992-1998 Mazda MX-3
1992-2001 Honda Prelude
1993-1997 Toyota Corolla
1993-1998 Nissan Skyline
1993-2001 Subaru Impreza
1994-1997 Honda Accord
1994-1999 Toyota Celica
1994-2001 Acura Integra
1995-1998 Nissan 240SX (coupe)
1995-1998 Nissan S14 (coupe)
1995-2005 Chevy Cavalier
1996-2000 Honda Civic
1996-2002 Toyota 4 Runner (Side brackets need to be flipped for 46-48" fitment)
1996-2000 Toyota Camry
1996-2001 Toyota Chaser / Mark ii / Cresta - JZX100 (Longer bolts needed for lower b-pillar)
1996-2001 Hyundai Tiburon
1996-2003 Mitsubishi Galant
1997-2001 Nissan Frontier
1997-2002 Mitsubishi Mirage
1998-2002 Honda Accord
1999-2002 Mercury Cougar
1999-2003 Mazda Protege
2000-2005 Dodge Neon/SRT-4
2000-2005 Toyota Celica
2000-2006 Nissan Sentra [requires reversing both ends on the harness bar to sit properly/flush]
2000-2006 Mitsubishi Lancer
2001-2005 Honda Civic
2001-2005 Lexus IS300 [requires reversing both ends on the harness bar to sit properly/flush]
2001-2006 Chrysler Sebring (sedan/convertible)
2001-2006 Dodge Stratus (sedan)
2001-2007 Honda Jazz
2002-2005 Honda Civic Si
2002-2006 Acura RSX
2002-2006 Nissan Altima
2002-2007 Mazda 6
2002-2007 Subaru Impreza/WRX/STi
2003-2007 Honda Accord (1)
2003-2007 Hyundai Tiburon
2003-2007 Mitsubishi Lancer Evolution
2003-2008 Saab 9-3 (sedan/wagon)
2003-2008 Toyota Matrix / Pontiac Vibe
2004-2006 Scion xB [requires reversing both ends on the harness bar to sit properly/flush; requires cutting into the pillar covers]
2004-2008 Acura TSX (1)
2004-2008 Nissan Maxima
2004-2009 Mazda 3
2010-2013 Mazda 3 / 2010-2013 Mazdaspeed 3 (1 or 2 side brackets needs to be flipped)
2004-2010 Scion tC**
2008-2010 Scion xB [requires reversing both ends on the harness bar to sit properly/flush; requires cutting into the pillar covers]
2005-2010 Chevy Cobalt (coupe)
2006-2008 Honda Fit
2007-2010 Nissan Altima (sedan)
2007-2010 Nissan Sentra
2006-2011 Honda Civic Si & Base Model
2011-2016 Honda Civic Si (Sedan/Coupe)
2008-2012 Honda Accord (coupe)
2008-2012 Mitsubishi Lancer/Evolution [requires removal or modifications to pillar covers]
2008-2014 Subaru Impreza WRX/STi (1)
2011-2022 Dodge Charger Scatpack **  (lower b-pillar plastic needs to be trimmed to mount bottom support bars)
2012-2020 Scion FR-S **
2012-2020 Subaru BRZ **
2012-2020 Toyota 86, GT86, FT86  **
2014-2018 Infiniti Q50 1st Gen (V37)** (flip 1 or 2 side mounts to fit 46-48" to retain factory seat belts)
2014-2016 Lexus IS 3rd Gen (XE30)
2017-2020 Lexus IS 3rd Gen (XE30) (1)
2020-         Lexus IS 3rd Gen (XE30)
2015-2018 Ford Focus ST
2015-2019 Subaru Impreza WRX/STi (1, 2, 3)
2017-2019 Honda Civic / Type R (Hatchback)
2013-2020 VW MK7/GTI (requires 2 sets of “7/16”- 20 thread size bolt)
2021+   Subaru BRZ **
2021+   Toyota GR86 **
